The BC548 NPN General Purpose Transistor is a widely used NPN bipolar junction transistor ideal for general-purpose switching and amplification. Common in driver circuits and low-power audio or signal amplifiers, it operates reliably with a collector-emitter voltage of 30 V and a continuous collector current up to 100 mA. Featuring high current gain up to 800, it’s suitable for various electronic applications including Darlington pair configurations.
Specifications:
| Parameter | Value |
|---|---|
| Transistor Type | NPN |
| Max Collector Current | 100 mA |
| Collector-Emitter Voltage | 30 V |
| Base Trigger Voltage | 5 V |
| Current Gain (hFE) | Up to 800 |
| Package Type | TO-92 (approx. 5.2 x 4.5 mm) |
Features:
- NPN-type bipolar transistor
- Collector current up to 100 mA
- Collector-emitter voltage: 30 V
- Base trigger voltage: 5 V
- High current gain: up to 800
- Compact TO-92 package
Package Includes:
- 1 x BC548 NPN General Purpose Transistor (Pack of 5)
