BT136 TRIAC – 4A, 600V | Bidirectional AC Switch | TO-220 Package
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
In Stock
16
People watching this product now!
Payment Methods:
Description
The BT136 is a general-purpose TRIAC suitable for AC switching applications. Capable of handling up to 4A continuous current and up to 600V, it’s ideal for medium-power AC loads like dimmers, motor speed controllers, and other power management circuits. Its gate can be triggered with low current (just 10mA), making it compatible with popular microcontrollers such as Arduino and Raspberry Pi.
Since it’s a bidirectional switch, it can conduct in both directions once triggered—making it highly efficient for alternating current (AC) control.
Features:
- Bidirectional AC control switch
- Compatible with 3.3V and 5V microcontroller logic
- Triggerable by both positive and negative gate pulses
- Supports up to 4A terminal current
- Compact TO-220 package for easy heatsink mounting
- Ideal for AC dimming, fan/motor speed control, and power control projects
Specifications:
| Parameter | Value |
|---|---|
| Max Terminal Current | 4A |
| Max Terminal Voltage | 600V |
| Gate Trigger Voltage | 1.4V |
| Gate Trigger Current | 10mA |
| Holding Current | 2.2mA |
| Latching Current | 4mA |
| Package Type | TO-220 |
| Control Type | Bidirectional |
Package Includes:
- 1 × BT136 TRIAC – TO-220 Package
