F550/Q550 Glass Fiber Hexacopter Frame Kit 550mm

The F550/Q550 Glass Fiber Hexacopter Frame Kit is a 550mm wheelbase six-arm drone frame made from ABS plastic center plates and glass fiber arms, designed for building a hexacopter — a six-motor multirotor that provides more lift capacity and motor redundancy than a four-motor quadcopter. With six motors, the hexacopter can continue to fly and land safely if one motor or ESC fails mid-flight, making it a more reliable platform for photography, payload, or long-endurance drone builds than a quadcopter of similar size. This f550 hexacopter frame includes an integrated PCB in the bottom center plate that distributes power from the battery to each ESC without requiring a separate power distribution board, simplifying the wiring and reducing component count in the build.

The hexacopter drone frame comes with six arms in three colors — two red, two white, and two black — which allows the builder to assign clockwise and counter-clockwise motor positions by arm color during assembly, making it easier to install propellers in the correct CW/CCW orientation without marking individual arms. Each arm measures 220mm × 55mm and has a 3mm motor mount hole diameter compatible with M3 mounting screws on standard brushless motors.

The 550mm wheelbase accommodates 2212 to 2216 series brushless motors with 9 to 10 inch propellers. The f550 q550 hexacopter frame’s ABS and glass fiber construction balances weight and impact resistance for a mid-size build platform. Available from StemVolt. This 550mm hexacopter frame kit is ideal for 6-motor brushless hexacopter use aerial photography and build payload drone.

Related Products:

• Checkout ZMR 250 FPV Drone Frame Kit

Features:

• 6-arm layout provides motor redundancy — survives one motor ESC failure
• Integrated PCB bottom plate eliminates need for separate power distribution board
• Color-coded arms (red white black) simplify CW CCW motor assignment
• 550mm wheelbase fits 2212-2216 motors with 9-10 inch propellers
• 3mm motor mount holes for standard M3 brushless motor mounting screws

Technical Specifications:

 Applications:

• 6-motor aerial photography hexacopter build with payload and camera mount
• Maker builds f550 hexacopter for FPV long-endurance drone flight
• STEM project for hexacopter drone frame 6-arm multirotor assembly demo
• Payload-carrying drone platform using 550mm hexacopter frame and 2212 motors

Package Includes:

• 1 x F550/Q550 Glass Fiber Hexacopter Frame Kit
