The JQ6500 MP3 Audio Sound Player is a compact audio playback board built around the JQ6500 chip. It runs on 3.3V to 5V DC and draws only 20mA at rated load, making it practical for battery-powered embedded builds. Audio files sit in built-in flash memory — no SD card slot, no FAT32 formatting required. The jq6500 mp3 sound player receives playback commands over UART serial from any microcontroller running at 3.3V or 5V logic.
One important limitation — this module stores MP3 files only. WAV or OGG formats are not supported. Audio output is mono, so stereo speaker setups will play identical signals on both channels. The non-obvious detail here is that the JQ6500 chip supports up to 115200 baud UART, which allows fast track switching in time-critical alarm or announcement applications.
The jq6500 mp3 module is used widely by Indian engineering students for voice announcement systems, smart doorbells, and interactive toy builds. The audio player module jq6500 requires no additional MP3 decoder chip or DAC — everything is integrated on the compact board itself.
StemVolt provides this sensor with trusted quality, ensuring reliable performance and easy usability.
Related Products:
- Checkout Micro SD Card Reader Module
Features:
- Built-in flash memory holds MP3 files without any external storage card
- UART serial interface controls playback at up to 115200 baud
- Rated current of 20mA keeps battery drain minimal in portable builds
- Mono audio output drives small speakers without external amplifier stage
Technical specifications:
| Specification | Details |
|---|---|
| Audio Format | MP3 |
| Operating Voltage | 3.3V to 5V DC |
| Storage Type | Built-in flash memory |
| Rated Current | 20mA |
| Audio Output | Mono |
| Module Type | Compact audio player board |
 Applications:
- Arduino doorbell plays recorded chime using JQ6500 MP3 Audio Sound Player
- Smart toy project plays animal sounds using mp3 audio module jq6500 onboard
- Security alarm system announces warnings through audio player module jq6500
Package Includes:
- 1 x JQ6500 MP3 Audio Sound Player Module
