GPS External Active Antenna with SMA Connector and 3 Meter Cable

The GPS External Active Antenna with SMA Connector is an amplified antenna (a signal-boosting receiver) that improves satellite reception for GPS modules with weak built-in ceramic antennas. The sma antenna connects via a standard SMA-Male plug and covers the GPS L1 band from 1570 to 1610 MHz, which is the frequency range used by all GPS satellites worldwide. It draws 15mA at 2.7V to 5V DC, meaning the GPS module itself supplies the power through the coaxial cable (the shielded signal wire inside the cable). No separate power connection is needed.

The non-obvious detail about the gps antenna is how the power actually reaches the active element. Inside the coaxial cable, the GPS module sends DC voltage through the centre conductor to power the LNA (Low Noise Amplifier — a chip that boosts weak satellite signals). If GPS module does not support this bias voltage on the antenna pin, the active element will not work and gain drops to near zero. Check your GPS module datasheet before purchasing. The honest trade-off is the cable length. A longer cable adds signal loss. The gain of 28dB ±2dB at the antenna element compensates for reasonable cable runs, but very long cables reduce the net gain at the receiver end.

The active gps with sma connector works with any GPS module that has an SMA female connector, including NEO-6M, NEO-7M, and similar boards used with Arduino and Raspberry Pi. improving GPS fix reliability, engineers mounting GPS modules inside enclosures, and makers building vehicle trackers all use this antenna. To start, screw the SMA connector firmly onto the GPS module port and place the antenna near a window or outdoors. StemVolt offers fast and reliable delivery of across India with trusted service support.

Related Products:

• Explore the Connectors and Cables for secure connections, reliable power transfer

Features:

• 28dB LNA gain amplifies GPS signal before cable transmission loss
• 1.5dB noise figure preserves weak satellite signal quality over cable
• SMA-Male connector fits NEO-6M NEO-7M and ublox M8N GPS modules
• 3-meter cable allows antenna placement at window or rooftop position
• 2.7V to 5V DC bias at 15mA suits all standard GPS module supplies

Technical specifications:

 Applications:

• GPS External Active Antenna used for NEO-6M Arduino GPS tracker build
• College project uses external gps antenna for vehicle location tracking demo
• Drone build uses active gps with sma connector for flight controller fix
• Weather station uses gps external active antenna for precise timestamp sync
• Raspberry Pi GPS logger uses sma antenna for outdoor location recording

Package includes:

• 1 x GPS External Active Antenna with SMA Connector
