The Servo Control Board Dual Channel PWM Servo Motor Driver respond to PWM pulses — a 1ms pulse commands full anticlockwise position, a 2ms pulse commands full clockwise, and a 1.5ms pulse centres the servo. The Servo Control Board Dual Channel generates those PWM pulses independently on two output channels at a 20ms cycle period, which is the standard timing that virtually all analogue and digital hobby servos expect. Control accuracy of 0.09° means the pulse width resolution is fine enough to position most standard servos to within a tenth of a degree, which is well within typical servo mechanical accuracy limits.
The servo controller operates from 5V to 9V DC, covering the supply range used by most standard plastic-gear servos at 5V and metal-gear digital servos at 6V to 7.4V. Two independent channels let the board drive two servos simultaneously without the channels affecting each other. The board receives position commands through its input interface from a host microcontroller — without an onboard processor, it functions as a PWM generation stage between the controller and the servo, not as a standalone controller.
Autonomous servo motion need to send position commands from an Arduino, the board does not store or execute motion sequences independently. The PWM servo motor control board suits pan-tilt camera mount drives, dual-axis gimbal control, and two-joint robotic arm. This servo motor driver board working on servo positioning systems and PWM motor control.
Related Product:
Features:
- 0.09° position accuracy provides fine angular resolution for precision servo
- 20ms PWM cycle matches standard timing requirement for analogue and digital servos
- Dual independent channels drive two servos simultaneously without cross-interference
- 5V to 9V DC supply covers standard and digital servo operating voltage ranges
- PCB format integrates cleanly into enclosure and chassis mounting positions
Technical Specifications:
Applications:
- Servo Control Board Dual Channel drives pan-tilt camera mount two-axis servo mechanism
- Positions dual-axis laser pointer gimbal for alignment and scanning
- Arduino servo motor control uses this board to drive two robot arm joint servos
- 2 channel servo motor controller drives two independent fin servos in RC aircraft
Package Includes:
- 1 x Servo Control Board Dual Channel PWM Servo Motor Driver
