L293D 4 Channel DC Motor Driver

The L293D 4 channel dc motor driver provides four independent H-bridge channels in a single IC, each capable of driving a brushed DC motor in forward or reverse direction from a logic level input signal. With four channels available, the IC drives four individual DC motors or two motors using paired channels for higher combined current capacity connecting two channels in parallel per motor doubles the current handling to 1.2A per motor pair from the standard 600mA per single channel.

The L293D motor driver, TTL and DTL logic compatibility connects directly to Arduino digital output pins at 5V without level shifting. The 4.5V to 25V motor supply range covers 5V BO motor, 9V battery powered chassis, 12V gear motor and 24V industrial control from the same IC. The dc motor driver onboard enable pins accept PWM input for proportional speed control on each channel duty cycle on the enable pin sets motor speed from stopped to maximum. Available on StemVolt. This driver is working on multi motor control and DC motor drive.

Related Product:

• Checkout Digital PWM DC Motor Speed Controller with LED Display

Features:

• H-bridge configuration enables forward and reverse motor direction control
• Two independent dual H-bridges drive two DC motors simultaneously
• 600mA per channel suits small hobby and robotics DC motors
• TTL logic compatible, direct 5V Arduino digital pin interfacing
• 4.5V–25V range suits 5V, 9V, and 12V motor power supplies

Technical Specifications:

Applications:

• L293D 4 channel dc motor driver drives four BO motors on four-wheel robot chassis
• Motor driver controls two gear motors in differential steering Arduino robot
• DC motor driver drives four actuators in multi-axis conveyor control panel
• 4 channel motor driver controls four small DC motors in animatronic puppet mechanism
• Driver controls four pump motors in multi-channel fluid dispensing system

Package Includes:

• 1 x L293D 4 Channel DC Motor Driver
