The Transparent Acrylic Case for Arduino UNO R3 is a simple, well-designed enclosure that protects your Arduino UNO board while keeping it fully accessible and visible. If you’re running a project on a desk, in a demonstration setup, or inside a cabinet, leaving the UNO board exposed is a risk — accidental shorts from loose wires, dust settling on the headers, or physical contact can cause unexpected failures. This case prevents all of that without getting in the way of your work.
The enclosure is built from six acrylic panels — top, bottom, and four sides — held together with copper pillar standoffs, M2.5 and M3 hex screws, and matching nuts, all included in the package. Assembly is straightforward and requires no special tools. The copper pillars raise the board off the base panel, providing adequate air circulation underneath.
What sets this case apart from generic enclosures is the precision of its cutouts. The USB port, DC power jack, ICSP programming header, and all digital and analog I/O pins remain fully accessible through the case walls. You can program the board, connect shields through the top, and power it without ever removing the board from the enclosure.
The full transparency of the acrylic also means your onboard LEDs — power indicator and pin 13 — are visible at all times, which is useful during debugging and demonstrations. Robotics developers, and hobbyists building arduino projects that need a finished, presentable look without the cost of a custom enclosure will find this a practical choice. StemVolt includes all mounting hardware so the case is ready to assemble right out of the box.
Related Products:
-
Explore the Data Logger Shield for Arduino Uno & Mega
Features:
- Acrylic Material — High optical clarity panels with smooth edges; resistant to minor impacts and surface scratches during regular project handling
- Full-Access Port Cutouts — Precision-cut openings for USB, power jack, ICSP header, and all I/O pin rows
- Board Visibility — Transparent panels allow visual monitoring of all onboard LEDs — power, TX, RX, and user LED — without opening the case
Technical Specifications:
| Specification | Details |
|---|---|
| Compatible Board | Arduino UNO R3 only |
| Material | high-quality transparent acrylic case |
| Color | Clear / Transparent (full board visibility) |
| Panel Count | 6 acrylic panels (top, bottom, and 4 sides) |
| Fastening Hardware | M2.5×10mm hex screws ×8, M3×6mm hex screws ×4, copper pillars ×4, M2.5 nuts ×8, M3 nuts ×4 |
| Port Access | Cutouts for USB port, power jack, ICSP header, and all I/O pins — no removal needed |
| Assembly Requirement | Hex screwdriver only — all hardware included |
Applications:
- Arduino Projects — Keeps the UNO board protected and presentable during science fair exhibits, project demonstrations, and lab setups
- Robotics Prototypes — Mount the enclosed UNO inside a robot chassis or frame without exposing the bare PCB to conductive surfaces or vibration damage
- IoT Demonstration Units — When presenting an IoT prototype to a client or at a hackathon, the enclosed board looks more finished and is safer to handle
- Educational Starter Kits — Commonly bundled with UNO boards and sensor kits as a protective housing for beginner electronics learning packages
Package Includes:
- 1 x Transparent Acrylic Case for Arduino UNO R3
